INNOVATIVE DESIGN BY D-D
Built in low iron high clarity glass, the aquarium features a braceless design producing a clean and modern display with easy access for maintenance tasks. A standard weir box can become an unattractive focal point in any aquarium, dictating aquascaping to try and hide it and interrupting flow patterns inside the tank. With this in mind, the invisible weir box of the PRO-Reef models has been carefully designed to minimise intrusion into the aquarium whilst exceeding the functionality found in most aquariums.
The PRO-Reef cabinet is designed to be tall to perfectly balance the aquarium and comes pre-assembled, designed and built by D-D in the U.K to ensure a consistent high quality and an extremely strong cabinet. The top, bottom and main structural uprights of the cabinet are made of 36mm waterproof board providing rigidity, excellent load bearing properties, giving the impression of a piece of furniture rather than just another tank cabinet.
There are two sections incorporated within the cabinet, the sump section and a second section for storage or designed to house a D-D DC750 chiller. The second section also has an adjustable shelf for general storage.
The tall cabinet provides good headroom for the use of taller equipment and ease of maintenance, we have also included a double fold back door and soft close hinges for even better access.
When installing an aquarium it is of the upmost importance to provide a level base, unlevelled cabinets can stress the glass and can result in an uneven water level in the aquarium. The D-D aquarium cabinet design includes heavy duty adjustable feet allowing for accurate leveling of the cabinet and aquarium.
OVERALL DIMENSIONS L x W x H (cm) 120 x 61 x 148
CABINET - 120 x 61 x 102 (cm)
AQUARIUM - 120 x 61 x 46 (cm)
SUMP – 67.5L x 46W x 38T (cm)
SYSTEM VOLUME - 365 Litres
AQUARIUM VOLUME - 300 Litres
SUMP VOLUME - 65 Litres
TOP UP VOLUME - 17.5 Litres
Twin 32mm Standpipes
1 x 20 mm rigid pump pipework
