Description
- 100% protection against eye damage
- Energy efficient thanks to electronic ballast
- Exceptionally effective sterilisation thanks to the long retention time of the water in the Bitron
- Flow-optimised reactor design ensures direct and virtually loss-free UV radiation
- High-quality V4A stainless steel housing for stability and good reflection rates
- Extremely easy installation with stainless steel connection elements
- Flexible connection upstream or downstream of the ProfiClear filter system — as well as for other gravity-fed applications
- In the event of pond enlargements or an increase in fish stock, extension with additional Bitron Premium UVC devices is possible at any time
- Visual function check
- Horizontal or vertical setup possible
- Clear water guarantee when used in conjunction with OASE ProfiClear filters
- Depending on requirements, the Bitron Premium 120 W and 180 W lamps can be switched on individually
60W
Dimensions (L x W x H) mm 700 x 290 x 205 Rated voltage 220 - 240 V / 50/60 Hz Power consumption W 60 Power cable length m 5.00 Net weight kg 7.30 Guarantee Years 2 UVC power W 60 UVC operating hours meter No Function check Visual Number of inlets Units 1 Inlet connections DN 110 Number of outlets Units 1 Outlet connections DN 110 Max. flow rate l/h 40000 Max. operating pressure bar 0.6 Rec. flow rate (gravity-fed) l/h 16500 Suitable for ponds up to max. m³ 90.0 Suitable for ponds with fish stock m³ 50.0 Suitable for ponds with koi m³ 33.0 Material Plastic / stainless steel Connection to AquaMax, ProfiClear Type of use Gravity fed system, Pump fed system
120W
Dimensions (L x W x H) mm 700 x 387 x 305 Rated voltage 220 - 240 V / 50/60 Hz Power consumption W 120 Power cable length m 7.00 Net weight kg 13.30 Guarantee Years 2 UVC power W 120 UVC operating hours meter No Function check Visual Number of inlets Units 1 Inlet connections DN 110 Number of outlets Units 1 Outlet connections DN 110 Max. flow rate l/h 70000 Max. operating pressure bar 0.6 Rec. flow rate (gravity-fed) l/h 33000 Suitable for ponds up to max. m³ 185.0 Suitable for ponds with fish stock m³ 100.0 Suitable for ponds with koi m³ 66.0 Material Plastic / stainless steel Connection to AquaMax, ProfiClear Type of use Gravity fed system, Pump fed system
180W
Dimensions (L x W x H) mm 700 x 417 x 340 Rated voltage 220 - 240 V / 50/60 Hz Power consumption W 180 Power cable length m 7.00 Net weight kg 17.40 Guarantee Years 2 UVC power W 180 UVC operating hours meter No Function check Visual Number of inlets Units 1 Inlet connections DN 110 Number of outlets Units 1 Outlet connections DN 110 Max. flow rate l/h 100000 Max. operating pressure bar 0.6 Rec. flow rate (gravity-fed) l/h 50000 Suitable for ponds up to max. m³ 280.0 Suitable for ponds with fish stock m³ 160.0 Suitable for ponds with koi m³ 100.0 Material Plastic / stainless steel Connection to AquaMax, ProfiClear Type of use Gravity fed system, Pump fed system
