Description
- Elimination of suspended algae (green water)
- Reduction of harmful bacteria and pathogen levels
- Clever UVC function monitor, display for bulb change and water temperature
- Bypass technology enables optimal irradiation of the polluted water, even at high flow through rates
- Individual water flow adjustment for optimal adaptation to the connected filter pump
- Integrated magnets protect the UVC technology against limescale deposits
- Visual function check of the UVC bulb
- 100% protection against eye damage
- Quick release technology for easy bulb replacement
- High-quality workmanship with impact resistant plastic housing
- Incl. high quality UVC bulb
- Including OASE Clear Water Guarantee in conjunction with the OASE flow through filters, BioSmart, BioTec and ProfiClear
24W
Dimensions (L x W x H) mm 440 x 180 x 198 Rated voltage 220 - 240 V / 50/60 Hz Power consumption W 24 Power cable length m 5.00 Net weight kg 3.50 Guarantee Years 2 UVC power W 24 Temperature display No Bypass control manually UVC operating hours meter No Function check Visual Number of inlets Units 1 Inlet connections mm 25 / 32 / 38 Inlet connections 1", 1 ¼", 1 ½" Number of outlets Units 2 Connections, outlet mm 25 / 32 / 38 Outlet connections 1", 1 ¼", 1 ½" Min. flow rate l/h 4000 Max. flow rate l/h 15000 Max. operating pressure bar 0.5 Suitable for ponds up to max. m³ 25.0 Suitable for ponds with fish stock m³ 12.5 Suitable for ponds with koi m³ 6.5 Connection to BioSmart 18000/36000
36W
Dimensions (L x W x H) mm 600 x 180 x 198 Rated voltage 220 - 240 V / 50/60 Hz Power consumption W 36 Power cable length m 5.00 Net weight kg 3.97 Guarantee Years 2 UVC power W 36 Temperature display No Bypass control manually UVC operating hours meter No Function check Visual Number of inlets Units 1 Inlet connections mm 19 / 25 / 32 / 38 / 50 Inlet connections ¾", 1", 1 ¼", 1 ½", 2" Number of outlets Units 2 Connections, outlet mm 25 / 32 / 38 Outlet connections 1", 1 ¼", 1 ½" Min. flow rate l/h 8000 Max. flow rate l/h 30000 Max. operating pressure bar 0.5 Suitable for ponds up to max. m³ 40.0 Suitable for ponds with fish stock m³ 20.0 Suitable for ponds with koi m³ 10.0 Connection to BioSmart 18000/36000, BioTec ScreenMatic² 40 - 60000
55W
Dimensions (L x W x H) mm 600 x 180 x 198 Rated voltage 220 - 240 V / 50/60 Hz Power consumption W 55 Power cable length m 5.00 Net weight kg 4.03 Guarantee Years 2 UVC power W 55 Temperature display No Bypass control manually UVC operating hours meter No Function check Visual Number of inlets Units 1 Inlet connections mm 19 / 25 / 32 / 38 / 50 Inlet connections ¾", 1", 1 ¼", 1 ½", 2" Number of outlets Units 2 Connections, outlet mm 25 / 32 / 38 Outlet connections 1", 1 ¼", 1 ½" Min. flow rate l/h 8000 Max. flow rate l/h 30000 Max. operating pressure bar 0.5 Suitable for ponds up to max. m³ 60.0 Suitable for ponds with fish stock m³ 30.0 Suitable for ponds with koi m³ 15.0 Connection to BioSmart 18000/36000, BioTec ScreenMatic² 40 - 60000
72W
Dimensions (L x W x H) mm 730 x 215 x 200 Rated voltage 220 - 240 V / 50/60 Hz Power consumption W 72 Power cable length m 5.00 Net weight kg 6.44 Guarantee Years 2 UVC power W 72 Temperature display No Bypass control manually UVC operating hours meter No Function check Visual Number of inlets Units 1 Inlet connections mm 19 / 25 / 32 / 38 / 50 Inlet connections ¾", 1", 1 ¼", 1 ½", 2" Number of outlets Units 2 Connections, outlet mm 25 / 32 / 38 Outlet connections 1", 1 ¼", 1 ½" Min. flow rate l/h 12000 Max. flow rate l/h 40000 Max. operating pressure bar 1 Suitable for ponds up to max. m³ 75.0 Suitable for ponds with fish stock m³ 37.5 Suitable for ponds with koi m³ 19.0 Connection to BioTec 30, BioTec ScreenMatic² 90 - 140000, ProfiClear
110W
Dimensions (L x W x H) mm 730 x 215 x 200 Rated voltage 220 - 240 V / 50/60 Hz Power consumption W 110 Power cable length m 5.00 Net weight kg 6.50 Guarantee Years 2 UVC power W 110 Temperature display No Bypass control manually UVC operating hours meter No Function check Visual Number of inlets Units 1 Inlet connections mm 19 / 25 / 32 / 38 / 50 Inlet connections ¾", 1", 1 ¼", 1 ½", 2" Number of outlets Units 2 Connections, outlet mm 25 / 32 / 38 Outlet connections 1", 1 ¼", 1 ½" Min. flow rate l/h 12000 Max. flow rate l/h 40000 Max. operating pressure bar 1 Suitable for ponds up to max. m³ 110.0 Suitable for ponds with fish stock m³ 55.0 Suitable for ponds with koi m³ 27.5 Connection to BioTec 30, BioTec ScreenMatic² 90 - 140000, ProfiClear
